The w. monogram: one icon, two repos

An icon is easy to dismiss as a detail — until your project is a fork, and the icon becomes the sharpest identity boundary between you and the parent project. At that point “draw the logo” stops being a pure design task: one shape has to live in two repos with two export pipelines, one side a web app consuming vectors, the other a desktop app needing icns and png. Wakii solves this the way wall builders always have: one geometry, everything else derived from it. This post reads both ends of that pipeline — from the SVG file on the site to the icon build script in the product repo — and lets the files make the argument themselves.

TL;DR:

• The “w.” icon is pure geometry, no font dependency — the decision is written in the file’s own comment, with the reason: fonts render inconsistently across platforms.
• On the site side, one master file wakii-icon.svg serves three consumers: the favicon (a twin with identical geometry), the GitHub avatar, and the OG image.
• On the app side, the icon is built from an Icon Composer project (icon.icon) through a generate.sh script — producing icon.icns for macOS and icon.png for tray and fallback.
• Icon history is recorded in commits, not in stories — three branding commits readable with one git log command.

The letter w., drawn as geometry, not font

Wakii’s entire visual identity fits in one SVG file. Its structure:

viewBox="0 0 128 128"
rect 128×128, rx=28, gradient #131A17 → #04140D
path "M26 42 L44 88 L64 48 L84 88 L102 42"
     stroke #45E0A8, width 13, round caps
circle cx=106 cy=86 r=8.5, fill #D7E2DD

Source: public/wakii-icon.svg, repo wakii-dev/wakii-site, retrieved 2026-09-08.

Three shapes: a dark rounded square with a gradient, one zigzag stroke drawing the letter w, one round dot. No <text> element — no font needed, no worrying about missing glyphs on some system. This decision has a recorded history, written in the favicon file itself:

<!-- wakii monogram icon — "w." drawn as geometry, no font
     dependency. Replaces the old <text>-based favicon
     (font rendering was inconsistent across platforms).
     Direction: The Monogram, 2026-09-05. -->

Source: public/favicon.svg, repo wakii-dev/wakii-site, retrieved 2026-09-08.

That comment briefly tells of an earlier failure: a previous favicon used <text> and suffered inconsistent font rendering across platforms. Pure geometry is the radical fix — your stroke renders identically everywhere because no font is asked to draw it for you. The design direction “The Monogram” also carries its selection date: 2026-09-05, after a three-direction draft.

One master, three site-side consumers

wakii-icon.svg is not just an icon sitting idle in public/. Its opening comment declares its role:

<!-- wakii icon symbol — "The Monogram" (chosen 2026-09-05,
     3-direction draft). Master file for reuse: favicon
     (public/favicon.svg is the small-size twin), GitHub
     avatar, og-image, Electron app icon source. -->

Source: public/wakii-icon.svg, repo wakii-dev/wakii-site, retrieved 2026-09-08.

Four consumers are declared in the comment — verify each. Favicon: favicon.svg contains the exact three shapes of the master (same viewBox, same path, same gradient, same dot), differing only in the comment — precisely what “small-size twin” means. Where it attaches to the HTML:

<link rel="icon" type="image/svg+xml" href="/favicon.svg" />

Source: src/layouts/Base.astro, line 84, repo wakii-dev/wakii-site, retrieved 2026-09-08.

The OG image — the card shown when links are shared — uses the icon’s exact palette, with the source written into the file: og-default.svg (1200×630) comments on its first line “brand mono ~/wakii. aesthetic (tokens.css: bg #0A0E0D, accent #45E0A8, text #D7E2DD, dim #6B7A74)”. That palette was not chosen for the card alone: it is the site-wide token set — the post on bento and tokens goes deep into that system, and the one on the OG article contract dissects the card from the SEO angle. One palette flowing from tokens.css through icon, favicon, and share card — that is what “one master” buys you: not a single file, but a single geometry and color source every surface derives from.

tokens.css (palette)
   │
   ├─► wakii-icon.svg ── geometry master
   │        ├─► favicon.svg  ── browser (Base.astro)
   │        ├─► GitHub avatar ── public repo
   │        └─► og-default.svg ── share card 1200×630
   │
   └─► icon.icon (Icon Composer) ── app side
            └─► generate.sh ──► icns + png

Source: diagram assembled from comments in wakii-icon.svg, Base.astro line 84, and og-default.svg — repo wakii-dev/wakii-site, retrieved 2026-09-08.

The app side: Icon Composer instead of SVG

The web eats fresh SVG, but the desktop does not live on plain vectors — macOS needs .icns with per-size slots, the tray needs a right-sized png. The product repo solves this with a dedicated build pipeline whose entry point sits in package.json:

"build:icons": "bash resources/icon-source/generate.sh"

Source: package.json, line 98, repo wakii-dev/wakii (local clone), retrieved 2026-09-08.

Reading the top of generate.sh exposes the pipeline’s single source:

# Generate app icons from Icon Composer .icon project
# Produces: resources/build/icon.icns (macOS),
#           resources/build/icon.png (fallback),
#           resources/icon.png (tray)

Source: resources/icon-source/generate.sh, repo wakii-dev/wakii, retrieved 2026-09-08.

The resources/icon-source/ directory indeed holds exactly two files: icon.icon — an Icon Composer project, Apple’s icon-building tool — and the generate.sh script. The script runs Xcode’s actool to compile the .icon into an .icns, then uses ImageMagick to trim the small slots. One comment in the script explains why this care is needed: “macOS list views use the small .icns slots directly” — macOS list views read the small slots of the icns directly, so every slot must be correct; you cannot freely scale up and down the way the web can.

The notable part is the two-master architecture: the site uses a plain SVG as its master, the app uses an Icon Composer project as its master. The two masters do not sync automatically — they are two embodiments of the same “w.” geometry, each kept in the format its environment needs. When the geometry changes, both change with one commit per repo — and git history records exactly that.

Icon changes are recorded in commits

Who changed what in the icon — the answer lives not in anyone’s memory but in the file’s history. The three most recent branding commits touching resources/icon.png in the product repo:

$ git log --oneline -3 -- resources/icon.png
b4149b602a brand: wakii monogram app icon — replace orca-era icon assets
d0d6fdefcf feat(brand): rename app display name to wakii
1cef5a2802 feat(brand): replace Orca logo/icon with HoiVu branding

Source: git log --oneline -3 -- resources/icon.png on the wakii-dev branch, local clone of the wakii-dev/wakii repo, retrieved 2026-09-08.

Those three lines narrate a full branding lifecycle: the old logo replaced with the HoiVu identity, the display name renamed to wakii, then the orca-era icon assets replaced outright with the monogram. Commit b4149b602a is the moment the monogram entered the app’s icon assets — on the wakii-dev branch, as of the date this post read the history; the post makes no further claim about which release contains it. How the app consumes these icons is also readable in code: src/main/app-icon.ts builds an APP_ICON_PATHS map with three runtime choices — classic (using icon.png in production, icon-dev.png in dev builds), plus watercolor and blue — allowing the app icon to switch at runtime, persisting the change through an AppleScript call into macOS NSWorkspace.

One geometry, two repos, two pipelines — and no link in the chain is a black box: every joint is a readable file, every change a traceable commit. “How is Wakii different from Orca” has many deep technical answers; the shortest one sits in your browser tab — a mint w. on a dark tile. Download Wakii and watch that icon land in your dock, or read the FAQ for more on the relationship between Wakii and Orca.
