Wakii site: bento layout and design tokens

The homepage of wakii.xyz looks like a bento board: cells of uneven sizes, sitting next to each other yet deliberately off-rhythm. That sense of discipline does not come from a UI framework. It comes from an old systems convention: a single source of truth. For this site, that source is a token file of roughly 45 lines. This post dissects how it works: the token contract, the 12-column grid, and a real overflow lesson learned when one cell had to host a fixed 680px board.

TL;DR:

• Every color, radius and spacing rhythm on the site lives in src/styles/tokens.css — plain CSS variables, with a comment forbidding renames.
• The bento grid is a plain 12-column CSS grid in src/components/landing/Bento.astro; six cells are laid out asymmetrically using only grid-column.
• A cell hosting a fixed 680px board has to live inside a shrinking track: min-width: 0 unlocks the shrink, an auto-scale script handles the picture.
• There is no dedicated 390px breakpoint: the grid collapses to one column at 1020px, and the board scales itself to whatever width remains.

One token file, the whole site answers to it

Open src/styles/tokens.css and the first thing you see is not a color value — it is the header comment:

/*
 * Wakii design tokens — "Modern Bento Premium" v2 (user-approved 2026-09-04).
 * Source of truth: docs/superpowers/designs/sf1-direction.md (BINDING, v2).
 * Fidelity target: docs/superpowers/designs/direction-d3-bento.html.
 * v1 Terminal Mono DNA (mono/mint/near-black) retained as identity base.
 *
 * SF-2/SF-3 consume these names — do not rename.
 */

Source: src/styles/tokens.css, lines 1-8, retrieved 2026-09-08.

The contract has three layers: an approved design file (sf1-direction.md), a token file that pins final values, and a rename ban for every component that consumes them later. The pinned values read directly from the file:

--bg: #0A0E0D;
--bg-card: #131A17; /* bento cells */
--accent: #45E0A8;
--text: #D7E2DD;
--radius-cell: 12px; /* bento cells (hand-off: 8–12px) */
--radius-btn: 6px;   /* buttons */
--bento-gap: 18px;
--wrap: 1240px;

Source: src/styles/tokens.css, retrieved 2026-09-08.

The detail worth noticing is the “hand-off” comments. The design file approved a range — bento cell radius 8-12px, bento gap 16-20px — and the token file pinned one value inside that range: 12px and 18px, with the original range noted right above the line. Anyone reading the code later can trace each value back to a design decision. The site is also dark-only: there is no light/dark toggle, and the declaration sits in the first lines of the global stylesheet:

html {
  scroll-behavior: smooth;
  color-scheme: dark;
}

Source: src/styles/global.css, lines 11-14, retrieved 2026-09-08.

body takes its background from var(--bg) and its text color from var(--text) — even the ::selection recolors to match the accent. No component gets to invent a color code.

The bento is a 12-column CSS grid, not a framework

The landing “bento” lives in exactly one component: src/components/landing/Bento.astro, holding six cells — the bracket canvas, the 9-agent grid, the gates strip, the memory log, the watchdog console, and figma-to-verify. Laying them out is a plain 12-column CSS grid:

.bento {
  display: grid;
  grid-template-columns: repeat(12, 1fr);
  gap: var(--bento-gap);
}
.bx-a { grid-column: 1 / 9; grid-row: 1 / 3; }
.bx-b { grid-column: 9 / 13; }
.bx-c { grid-column: 9 / 13; }
.bx-d { grid-column: 1 / 6; }
.bx-e { grid-column: 6 / 10; }
.bx-f { grid-column: 10 / 13; }

Source: src/components/landing/Bento.astro, retrieved 2026-09-08.

Those six grid-column lines draw the entire layout:

 cols →  1         5         9    12
        ┌───────────────────┬────────┐
        │                   │   B    │
        │         A         ├────────┤
        │   bracket canvas  │   C    │
        │  1/9 · rows 1→3   │  9/13  │
        ├────────┬──────────┴───┬────┤
        │   D    │      E       │ F  │
        │  1/6   │    6/10      │10/13│
        └────────┴──────────────┴────┘

Source: diagram built from the grid-column values in src/components/landing/Bento.astro, retrieved 2026-09-08.

Cell A spans 8 columns and 2 rows — that is the bracket canvas, the lead character. The bottom row is split among three cells at three different widths: 5, 4 and 3 columns. No media query touches this layout layer; “deliberate asymmetry” is just arithmetic over grid tracks, and the gap between cells is literally one token: var(--bento-gap).

min-width: 0 and the 680px board

Inside cell A sits the bracket canvas — an SVG board with a fixed 680×400 coordinate space. This is where the grid hits a classic problem: by default a grid item has min-width: auto, meaning it never shrinks below its content. The 680px board would push its track wide and wreck the 12 columns. The fix sits right in Bento.astro:

.bx {
  will-change: transform;
  /* cho phép track co dưới min-content của board 680px (scale script lo hình) */
  min-width: 0;
}

Source: src/components/landing/Bento.astro, lines 130-134, retrieved 2026-09-08.

min-width: 0 alone only unlocks shrinking — the picture would still break if nothing squeezed the content. That part belongs to BracketCanvas: a script measures the container’s real width and scales the whole board by that ratio:

const s = Math.min(1, outer.clientWidth / 680);
board.style.transform = `scale(${s.toFixed(4)})`;

Source: src/components/mockups/BracketCanvas.astro, scaleAll function, retrieved 2026-09-08.

That pair is why you will not find a 390px breakpoint anywhere in src/ — grep source files only (*.astro, *.ts, *.css), excluding src/content/, and 390 returns zero lines. At 1020px, the component’s single media query collapses the grid to one column; below that, the board scales itself to the width left over after the 32px side padding of .wrap. The min-width: 0 pattern is not unique to Bento either: a grep across src/ counts 17 occurrences at the time of writing, from PostCard to DocsLayout. It is a lesson that was paid for with a broken layout, then written down as a repo-wide convention.

A one-way chain: direction → tokens → components → pages

The system only works because values flow one way. No component invents a color, no page sets its own radius:

docs/superpowers/designs/sf1-direction.md    (BINDING, approved 2026-09-04)
        │  pinned values
        ▼
src/styles/tokens.css        ← CSS variables, no UI classes
        │  var(--radius-cell), var(--bento-gap), var(--accent)…
        ▼
src/components/landing/*.astro + src/layouts/*.astro
        │  consume tokens, never hardcode values
        ▼
src/pages/index.astro (EN, 10 lines) · src/pages/vi/index.astro (VI, 9 lines)

Source: real paths in the public repo wakii-dev/wakii-site; line counts taken in the worktree, retrieved 2026-09-08.

The homepage is a thin wrapper: 10 lines for EN, 9 for VI, each just wrapping the Landing component and injecting the right string pack. The same token set flows down into blog and docs — the post detail layout src/layouts/BlogDetailLayout.astro is among the 17 min-width: 0 spots mentioned above. At the 2026-09-08 snapshot — after the first longform batch, before the current one — the blog held 25 slugs × 2 locales = 50 files, and all of them render on the same token foundation.

A token change therefore has no shortcut: it goes through the repo’s public build chain — parity gate → utility gate → content lint → astro build. The post log 2 of the building-in-the-open series dissects that chain layer by layer; here it is enough to add that the one-place-ness of tokens is what keeps that chain short enough to trust.

Questions about the site and the product are collected on the FAQ page. To see how this site itself got built, the best starting point is case study: this blog is a running story.

To watch the bento cells move, open wakii.xyz and hover over them. To get a token system like this in your own project, start at the getting started page — the kit installs with one command; the rest is convention.
