AI diff annotation: reviews that carry their reasons

An agent finishes its edits, a human opens the diff and leaves a few comments — and the cycle repeats out of habit: the comments stay in the browser, the agent moves on without reading them. The reason behind each change — why this line had to change, which criterion failed — sits exactly where the agent cannot see it. Wakii aims straight at that break point: a review note is pinned to the diff line itself, composed against the placeholder “Add note for the AI”, then sent back to the running agent session. This post reads that mechanism straight from the code, now that it has shipped in v1.4.199.

TL;DR:

A review note is not a separate tab — it is data attached to a file and a line: composed in a popover, displayed by a card pinned inside a Monaco view zone, right under the annotated line.
The “This note” button formats a note into a prompt and sends it to the agent session; a note already sent is excluded from the next send (“Note already sent”).
On the PR page, GitHub review comments are pinned back onto the current lines of the code; outdated threads are dropped from the inline row so a comment cannot attach to the wrong line.
Limits stated plainly: this is a mechanism for carrying reasons back to the agent — the card does not edit code by itself and calls no model.

Comments live outside the agent’s head

The default review loop has a structural gap, not a diligence problem. The diff lives inside the agent’s tooling; the comments live in a browser. The two halves do not meet: the agent picks up the next fix without carrying the reason for the previous one, and the reviewer re-types context into every fresh prompt:

the leaky review loop — the reason sits where the agent cannot read

  agent edits code → diff opens → human reviews
                                      │ comment lands in a browser / GitHub
                                      ▼
  agent moves on  ◄── new prompt carries no comment
                       → the fix arrives, the reason does not

Source: conceptual diagram of the gap the feature-wall tile-08 caption names (“ship them back to the agent”), retrieved 2026-09-08.

The cost does not stop at inconvenience. A review comment without context forces the agent to guess intent, and every guess is another diff that needs reviewing again. To cut that loop, the reason has to live in the same place as the code — which is what the next two sections show in real code.

Pinning a note to the diff line

Composing and displaying are two components in one directory, src/renderer/src/components/diff-comments/. The composer is DiffCommentPopover: a DOM overlay beside the editor (the author states the intent in the file’s first comment — to own a React auto-resizing textarea instead of a Monaco-internal widget). The placeholder and button label are prop defaults, not marketing copy:

# src/renderer/src/components/diff-comments/DiffCommentPopover.tsx, prop defaults
  placeholder = 'Add note for the AI',
  submitLabel = 'Add note',

Source: src/renderer/src/components/diff-comments/DiffCommentPopover.tsx, lines 42-43, tag v1.4.199, retrieved 2026-09-08.

The popover title is computed from the selected line: “Line 42”, or “Lines 40-42” when a range is selected (startLine differs from lineNumber). Enter submits, Shift+Enter inserts a newline, Escape cancels; an outside click only closes the popover when the draft is empty — a draft with text keeps it open. The display side is DiffCommentCard, and its position is the core of the mechanism: the card does not open in a side panel — it sits inside a Monaco view zone, at the exact annotated line:

# src/renderer/src/components/diff-comments/DiffCommentCard.tsx, first comment
// Why: the saved-note card lives inside a Monaco view zone's DOM node.
// useDiffCommentDecorator creates a React root per zone and renders this
// component into it so we can use normal lucide icons and JSX ...

Source: src/renderer/src/components/diff-comments/DiffCommentCard.tsx, lines 8-11, tag v1.4.199, retrieved 2026-09-08.

On the card, a quote block shows the code the note is attached to — context is visible without scrolling up. The meta line joins the author (defaulting to “Note”), the line label, and a “sent” marker once the note has been sent. The card also keeps the zone height in sync through a ResizeObserver so it cannot overlap the lines below when text wraps in a narrow pane. One naming detail worth noticing: user-facing copy says “Note” rather than “Comment” — the author’s stated reason is to avoid confusion with GitHub PR review comments, which some diff surfaces also render.

On the PR page, GitHub comments pin to current lines

The other half of the mechanism lives on the PR page. The buildInlineReviewComments function in src/renderer/src/components/pull-request-page/files/inline-comments.ts takes a PR’s GitHub comments and returns DecoratedDiffComment — the data shape the card understands: filePath from comment.path, the pinned line from comment.line, side: 'modified'. Three kinds of comments are dropped from the inline row, and the reason sits in the code as a comment:

# src/renderer/src/components/pull-request-page/files/inline-comments.ts
// Why: outdated threads keep originalLine for the sidebar, but rendering it
// inline can attach the comment to unrelated current code.
if (comment.isOutdated || !comment.path || typeof comment.line !== 'number') {
  return []
}

Source: src/renderer/src/components/pull-request-page/files/inline-comments.ts, tag v1.4.199, retrieved 2026-09-08.

Read that Why line closely: outdated threads keep their original line number for the sidebar, but rendered inline the comment could attach to current code it has nothing to do with. That is the right review call: a comment pinned to the wrong line is worse than a hidden one — the reader would trust a false context. These GitHub comments are also read-only inside the app: they are built with canDelete: false and canEdit: false, and the card only renders Edit/Delete buttons when a callback exists — no callback, no button; editing happens on GitHub through the “Open” button.

Tile-08 and the loop that closes back to the agent

The app’s feature-wall registry records the design intent as one tile:

$ grep -n "Inline review" src/shared/feature-wall-tiles.ts
144:    title: 'Inline review, back to the agent',

Source: src/shared/feature-wall-tiles.ts, tile-08 (kind “media”, owner “diff-review”), caption verbatim: “Drop markdown comments on any diff line, batch them, ship them back to the agent. Inspect CI, resolve conflicts, open PRs - all in-app.”, retrieved 2026-09-08.

“Back to the agent” is not a slogan — it has a real button. In diff-comment-zone-card.tsx, the card’s action row receives headerActions as a NotesSendMenu when the note is a local one (its author is undefined), scoped “This note”: the note is formatted into a prompt and sent to the agent session of the running worktree. A note carrying sentAt is excluded from the next send — the status tooltip reads “Note already sent” — and after a successful delivery, clearDeliveredDiffComments clears the delivered note from the diff:

the review loop closing back to the agent

  agent edits code
       │ new diff
       ▼
  note pinned to the diff line ◄── human composes "Add note for the AI"
       │ "This note" button → prompt
       ▼
  agent session receives the prompt → fixes per the reason → new diff + notes

Source: built from src/renderer/src/components/diff-comments/diff-comment-zone-card.tsx (NotesSendMenu, formatCommentPrompt, clearDeliveredDiffComments), retrieved 2026-09-08.

The difference from the leaky loop at the top of this post comes down to one thing: the reason is no longer re-typed into a fresh prompt — it travels with the diff, as a note pinned to the line, and the agent receives exactly that text.

Where the loop stops

No model appears in these files, and this post names none: the card does not edit code by itself, does not generate patches. It carries the reason back to the agent; the fixing stays the agent’s job, and the verdict stays with the independent reviewer — gates, not trust — and Rule 0 covers why a green checkmark is not a substitute for opening the result.
On the PR page, GitHub comments are read-only in the app: no Edit, no Delete, only an “Open” button leading back to GitHub.
Outdated threads do not render inline — they stay in the sidebar; the inline row only carries comments that pin onto current code.
This post’s scope is the component layer it read: the card, the popover, the inline-comment builder on the PR page, and the tile registry. Send state lives in the diffComments store slice — the post does not go deeper:

$ grep -n "export type DiffCommentDeliverySnapshot" src/renderer/src/store/slices/diffComments.ts
32:export type DiffCommentDeliverySnapshot = Pick<

Source: src/renderer/src/store/slices/diffComments.ts, tag v1.4.199, retrieved 2026-09-08.

Questions about review loops, gates and other qa mechanisms are collected on the FAQ page.

To see the loop yourself: open a diff in Wakii, click a line, type a note for the AI, press “This note” — and read the agent receiving your reason in the running session.
